| Manufacturer | Hirose Electric Co Ltd | |
|---|---|---|
| Series | HRM(V) | |
Packaging  | Bulk | |
| Part Status | Active | |
| Connector Style | SMA | |
| Connector Type | Jack, Female Socket | |
| Contact Termination | Solder | |
| Shield Termination | Solder | |
| Impedance | 50 Ohm | |
| Mounting Type | Panel Mount | |
| Mounting Feature | Flange | |
| Cable Group | - | |
| Fastening Type | Threaded | |
| Frequency - Max | 18GHz | |
| Number of Ports | 1 | |
| Features | Extended Insulation | |
| Housing Color | Silver | |
| Ingress Protection | - | |
| Includes | - | |
| Body Material | Stainless Steel | |
| Body Finish | - | |
| Center Contact Plating | Gold | |
| Dielectric Material | Polytetrafluoroethylene (PTFE) | |
| Operating Temperature | -55°C ~ 85°C | |
| Center Contact Material | Beryllium Copper | |
| Mating Cycles | 500 | |
| Insertion Loss | - |
