| Manufacturer | Lite-On Inc. | |
|---|---|---|
| Series | - | |
Packaging  | Cut Tape (CT) | |
| Part Status | Active | |
| Color | Green | |
| Configuration | Standard | |
| Lens Color | Colorless | |
| Lens Transparency | Clear | |
| Millicandela Rating | 260.5mcd | |
| Lens Style | Rectangle with Flat Top | |
| Lens Size | 1.10mm x 0.80mm | |
| Voltage - Forward (Vf) (Typ) | 3.2V | |
| Current - Test | 20mA | |
| Viewing Angle | 130° | |
| Mounting Type | Surface Mount | |
| Wavelength - Dominant | 525nm | |
| Wavelength - Peak | 530nm | |
| Features | - | |
| Package / Case | 0603 (1608 Metric) | |
| Supplier Device Package | Chip LED | |
| Size / Dimension | 1.60mm L x 0.80mm W | |
| Height (Max) | 0.65mm |
