| Manufacturer | Phoenix Contact | |
|---|---|---|
| Series | SACC | |
Packaging  | Bulk | |
| Part Status | Active | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 4 | |
| Shell Size - Insert | M12-4 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line), Angled | |
| Mounting Feature | - | |
| Termination | IDC | |
| Fastening Type | Threaded | |
| Orientation | D | |
| Shell Material | Brass | |
| Shell Finish | Nickel | |
| Contact Finish - Mating | Gold | |
| Color | Silver | |
| Ingress Protection | IP67 - Dust Tight, Waterproof | |
| Material Flammability Rating | UL94 V-0 | |
| Features | Backshell | |
| Shielding | Shielded | |
| Current Rating | 1.75A | |
| Voltage Rating | 48VAC, 60VDC | |
| Backshell Material, Plating | Zinc Die Cast, Nickel | |
| Cable Opening | 0.157" ~ 0.315" (4.00mm ~ 8.00mm) | |
| Contact Material | Copper Tin | |
| Contact Finish Thickness - Mating | - | |
| Insert Material | Polyamide (PA66), Nylon 6/6 | |
| Operating Temperature | -40°C ~ 85°C | |
| Applications | - |
