| Manufacturer | Amphenol Industrial Operations | |
|---|---|---|
| Series | Military, MIL-DTL-26482 Series I, PT | |
Packaging  | Bulk | |
| Part Status | Active | |
| Connector Type | Receptacle, Male Pins | |
| Number of Positions | 3 | |
| Shell Size - Insert | 12-3 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount | |
| Mounting Feature | Flange | |
| Termination | Solder Cup | |
| Fastening Type | Bayonet Lock | |
| Orientation | N (Normal) | |
| Shell Material | Aluminum | |
| Shell Finish | Olive Drab Chromate over Cadmium | |
| Contact Finish - Mating | Gold | |
| Color | Olive Drab | |
| Ingress Protection | Environment Resistant | |
| Material Flammability Rating | - | |
| Features | - | |
| Shielding | Unshielded | |
| Current Rating | - | |
| Voltage Rating | - | |
| Backshell Material, Plating | - | |
| Cable Opening | - | |
| Contact Material | Copper Alloy | |
| Contact Finish Thickness - Mating | - | |
| Insert Material | Neoprene | |
| Operating Temperature | -55°C ~ 125°C | |
| Applications | Aerospace, Communication Systems, Industrial, Instrumentation, Mass Transit, Military |
